Conex Basic Security

BATTERY NOT INCLUDED. FOR REFERENCE ONLY

Includes:

• Water resistant enclosure with hinged cover (13" H x 9.2" L x 5.6" W)
• Control module
• (2) Key fobs
• Siren and strobe combo
• (2) Heavy duty magnetic door sensors
• LED indicator
• Insurance rebate card
• Warranty card

Conex Alarm System

Built to protect conex boxes and storage containers from theft and unauthorized access.

This system is mounted inside the container to keep critical components protected from weather, tampering, and harsh job site conditions.

It monitors for door openings and movement. If a breach is detected, it activates the siren and strobe and can send alerts to your phone, depending on the model selected.

The goal is simple.

Stop theft before it happens.

This is not a repurposed trailer or vehicle system. It is designed specifically for containers used on job sites, storage yards, and remote locations.

The enclosure is large enough to accommodate a small 12-volt lithium battery, approximately 5Ah in size. For uninterrupted operation, the battery will require a solar panel or trickle charger to maintain proper charge levels.

Key benefits:

• Hidden, protected installation inside the container
• Loud on-site deterrent with siren and strobe activation
• Alerts when doors are opened or the container is moved
• Built for real-world job site use
• Simple to operate with no unnecessary features

Specifications:

• Maximum Voltage: 15 VDC
• Operating Temperature: Up to 185°F
• Current Draw (Armed): 7 mA
• Current Draw (With Optional LED): 19 mA
